Helicopter Specifications & Performance
| Fuselage Dimensions | SIKORSKY S-76C+ |
|---|---|
| Length (ft): | 43.3 |
| Height (ft): | 11.8 |
| Width (ft): | 10.0 |
| Typical Configuration | |
| Crew: | 2 |
| Passengers: | 12 |
| Fuel Capacity | |
| Standard (lbs): | 1,912 |
| Standard (gal): | 285 |
| Optional (lbs): | 694 |
| Optional (gal): | 104 |
| Weight | |
| Max. Takeoff (lbs): | 11,700 |
| Empty Operating Weight (EOW): | 7,091 |
| Speed Knots | |
| Normal Cruise TAS: | 140 |
| Vmo (Max Op) IAS: | 155 |
| IFR Certification: | |
| (IFR): | 1 Pilot |
| Climb | |
| Normal (fpm): | 1,625 |
| Engine Out (fpm): | |
| Ceiling (ft): | 12,700 |
| (HOGE) Out of Ground Effect: | 1,800 |
| (HIGE) In Ground Effect: | 5,650 |
| Range (Nautical Miles) | |
| Tanks Full (nm): | 435 |
| Seats Full (nm): | 427 |
| Engines | |
| Number of: | 2 |
| Model(s): | Arriel 2S1 |
| Thrust (lbs per Engine): | 0 |
| Shaft (hp per Engine): | 794 |
| Common TBO Hours: | 3,500 |
